2021 Chevrolet 4500 LCF Gas
2021 Chevrolet 4500 LCF Gas
Visit our Store
- Crossroads Ford Indian Trail
-
88 Dale Jarrett Blvd
Indian Trail, NC 28079
- Sales: 704-448-9312
- Service: 704-261-8801
- Parts: 704-283-0616
- Commercial Sales: 704-774-4952
Vehicle Information
VIN:
54DCDJ1D6MS203828
Stock #:
T268153A
Model Code:
CP34043
-
Body Style Crew Cab Chassis-Cab -
Exterior Color White
-
Mileage 66,599
-
Engine 8 Cyl - 6.6 L -
Transmission Automatic -
Fuel Type Gasoline Fuel
Highlighted Features
Feature availability subject to final vehicle configuration. Please reference window sticker for more info.
- Bluetooth®
- Keyless Entry
- Cruise Control
Eligible Benefits
All Features
- Assist steps
- Glass, tinted
- Mirror, outside left hand and right hand dual cab mounted exterior with integral convex mirror
- Tires, front, 225/70R19.5 G 128/126 L BW HWY VAR1
- Tires, rear, 225/70R19.5 G 128/126 L BW HWY VAR1
- Wheels, 19.5" x 6", K steel
- Windshield wiper, pulse, wet arm
- Air conditioning, single-zone manual, integral in-dash mounted
- Audio system feature, 2 speakers
- Audio System, AM/FM stereo with CD player, auxiliary jack, USB port and Bluetooth®
- Cruise control, electronic, automatic
- Cup holders
- Door locks, power
- Driver Information Center
- Floor mats
- Lighting, interior dome
- Seat trim, Cloth
- Seat, front high back bucket driver and passenger tricoat cloth covered reclining highback driver seat with single two occupant fold down passenger seat
- Steering column, Tilt-Wheel
- Steering wheel, urethane
- Storage, door pockets
- Storage, seatback pockets
- Windows, power
- Windshield washer bottle access on passenger side dash when passenger-side door is open
- Air cleaner, heavy-duty, 11" diameter dry paper single element. Air cleaner canister standard with air restriction gauge. Back of cab location.
- Alternator, 145 amps output with integral regulator
- Axle, 4.30 ratio (Standard on 4500 model only.)
- Battery, 750 cold-cranking amps, 12-volt single, maintenance free, frame-mounted battery box
- Drivetrain, rear-wheel drive
- Exhaust, single outlet
- Frame, ladder-type channel frame. Full C section straight frame 33.5" (85.1 cm) wide. Yield strength 44,000 psi, section modulus 7.20 cu.in. and RBM 316,800 lb-ft/in per rail.
- Front axle, 6,830 lbs. (3098 kg), reverse Elliot "I"-beam includes integral hydraulic power steering. ratio 18.8-20.9:1
- Front suspension, 8,440 lbs. (3828 kg) tapered leaf, semi-elliptical steel alloy tapered leaf springs. Includes shock absorbers and stabilizer bar.
- Fuel tank, 38.6 Gallon, (146L), rectangular fuel tank. mounted between frame rail with electric type fuel pump (mounted in tank). Through the rail fuel fill.
- GVWR, 14,500 lbs. (6577 kg)
- Incomplete vehicle certification
- Rear axle, 11,020 lbs. (4998 kg) R050, full-floating single-speed with oil lubricated rear wheel-bearings
- Rear suspension, 12,900 lbs. (5851 kg), multi-leaf, semi-elliptical steel alloy. Includes shock absorbers
- Vehicle Application Truck
- Wheelbase, 176" (447.0 cm)
- Daytime Running Lamps
- ARC WHITE
- ENGINE 6.6L V8 SIDI GMPT-V8 8 CYLINDER V IRON BLOCK FOUR CYCLE OVERHEAD valve water cooled 6.6L SIDI V8 350 hp [261 kW] @ 4500 rpm 425 lb.-ft of torque [575.8 N-m] @ 3800 rpm. Electronically controlled direct fuel injection. Six bolt main cap design for heavy-duty performance. Engine Control Module (ECM) and Transmission Control Module (TCM) engine control system. Engine cruise control engine oil cooler High Idle Mode (1200 rpm). (STD)
- TRANSMISSION 6-SPEED AUTOMATIC 6L90-E HYDRA-MATIC WITH LOCK-UP CONVERTER AND OVERDRIVE. Ratios: Gear and Ratios 4.027 2.364 1.532 1.152 0.852 0.667 Rev. 3.064:1 (STD)
- VERY DARK PEWTER CLOTH SEAT TRIM
- SEAT FRONT HIGH BACK BUCKET DRIVER AND PASSENGER tricoat cloth covered reclining highback driver seat with single two occupant fold down passenger seat (STD)
- AUDIO SYSTEM AM/FM STEREO WITH CD PLAYER AUXILIARY JACK USB PORT AND Bluetooth® (STD)
- AXLE 4.30 RATIO
- PREFERRED EQUIPMENT GROUP includes standard equipment
- PIO FIRE EXTINGUISHER AND SAFETY REFLECTOR MOUNTING PROVISIONS (Port Installed Option)
- PIO REMOTE KEYLESS ENTRY (Port Installed Option)
- Preferred Equipment Group 1WT
- 2 Speakers
- AM/FM radio
- CD player
- Radio: AM/FM Stereo w/CD Player & Bluetooth®
- Air Conditioning
- Single Zone Manual Air Conditioning
- Power steering
- Power windows
- Remote Keyless Entry
- ABS brakes
- Front anti-roll bar
- Fire Extinguisher & Safety Reflector Mounting Provisions
- Speed control
- Dual rear wheels
- Bumpers: body-color
- Driver door bin
- Overhead console
- Tachometer
- Telescoping steering wheel
- Tilt steering wheel
- Trip computer
- Front Bucket Seats
- Front Center Armrest
- Front High Back Bucket Seats
- Tricoat Cloth Seat Trim
- Passenger door bin
- Wheels: 19.5 x 6.0 K Steel
- Brake ABS System: 4-Wheel
- Brake Type: Pwr
- Disc - Front (Yes or ): Yes
- Drum - Rear (Yes or ): Yes
- Front Brake Rotor Diam x Thickness (in): 11.5 x
- Rear Drum Diam x Width (in): 12.6 x 3.94
- Cold Cranking Amps : 0° F (2nd)
- Cold Cranking Amps : 0° F (3rd)
- Cold Cranking Amps : 0° F (Primary)
- Maximum Alternator Capacity (amps): 145
- Body Length Default Value (ft): 14
- Cab to Axle (in): 114.5
- Cab to End of Frame (in): 157.6
- Frame Width, Rear (in): 33.5
- Front Bumper to Back of Cab (in): 109.9
- Ground Clearance, Front (in): 8.3
- Ground Clearance, Rear (in): 8.3
- Ground to Top of Frame (in): 33.0
- Height, Overall (in): 91.9
- Length, Overall (in): 267.5
- Overhang, Front (in): 48.4
- Overhang, Rear w/o bumper (in): 43.1
- Wheelbase (in): 176.0
- Width, Max w/o mirrors (in): 81.3
- Frame RBM (N/A): 316800
- Frame Strength (lbs): 44000
- Frame Thickness (in): 8.50 X 2.76 X 0.24
- Frame Type: Ladder-Type C-Section
- Sect Modulus Rails Only (in³): 7.20
- Fuel Tank Capacity, Approx (gal): 38.6
- Fuel Tank Location: Frame Rail
- Front Head Room (in): 38.40
- Front Hip Room (in): 67.70
- Front Leg Room (in): 29.50
- Front Shoulder Room (in): 70.70
- Passenger Capacity: 7
- Second Head Room (in): 37.30
- Second Hip Room (in): 69.30
- Second Leg Room (in): 22.30
- Second Shoulder Room (in): 69.30
- Torque : Clutch Engage (ft-lbs)
- Torque Converter: 2.6
- Steering Ratio (:1), At Lock: 18.8 - 20.9
- Steering Ratio (:1), On Center: 18.8 - 20.9
- Steering Type: Pwr
- Turning Diameter - Curb to Curb (ft): 51.9
- Turning Diameter - Wall to Wall (ft): 57.2
- Body Style: Crew Cab Chassis Cab
- Vehicle Name: Chevrolet 4500 LCF Gas
- Axle Capacity - Front (lbs): 6830
- Axle Capacity - Rear (lbs): 14550
- Axle Ratio (:1) - Rear: 4.30
- Axle Type - Front: I-Beam
- Axle Type - Rear: Full-Floating
- Shock Absorber Diameter - Front (mm): 42.0
- Shock Absorber Diameter - Rear (mm): 42.0
- Spring Capacity - Front (lbs): 8440
- Spring Capacity - Rear (lbs): 12900
- Stabilizer Bar Diameter - Front (in): 1.65
- Suspension Type - Front: Semi Elliptical Spring
- Suspension Type - Rear: Multi-Leaf Spring
- Front Tire Capacity (lbs): 6630
- Front Tire Order Code: 2TC
- Front Tire Size: 225/70R19.5
- Number Of Tires Front: 2
- Number Of Tires Rear: 4
- Rear Tire Capacity (lbs): 12460
- Rear Tire Order Code: 3TC
- Rear Tire Size: 225/70R19.5
- Revolutions/Mile : 45 mph - Front
- Revolutions/Mile : 45 mph - Rear
- Revolutions/Mile : 45 mph - Spare
- Number of Passenger Doors: 4
- Curb Weight - Front (lbs): 3979
- Curb Weight - Rear (lbs): 2292
- Gross Axle Wt Rating - Front (lbs): 6630
- Gross Axle Wt Rating - Rear (lbs): 11020
- Gross Combined Wt Rating (lbs): 14500
- Gross Vehicle Weight Rating Cap (lbs): 14500
- # of Bolt Holes - Front: 6
- # of Bolt Holes - Rear: 6
- Front Bolt Pattern: 6 Hole JIS 8.75"
- Front Wheel Material: Steel
- Front Wheel Offset (mm): 127
- Front Wheel Size (in): 19.5 x 6.0
- Rear Bolt Pattern: 6 Hole JIS 8.75"
- Rear Wheel Material: Steel
- Rear Wheel Offset (mm): 127
- Rear Wheel Size (in): 19.5 x 6.0
